No.
|
Dimension
|
Fixing holes
|
Gear teeth
|
Tooth force
|
Basic load ratings
|
Weight
|
|
Static
|
Dynamic
|
|
Da
|
Di
|
di
|
da
|
La
|
Li
|
na
|
ni
|
do
|
m
|
z
|
Fz norm
|
Fz max
|
Cor
|
Coa
|
Cr
|
Ca
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
-
|
-
|
mm
|
mm
|
-
|
kN
|
kN
|
kN
|
kN
|
kN
|
kN
|
kg
|
|
010.20.0314
|
386
|
315.5
|
242
|
312.5
|
360
|
268
|
20
|
20
|
/
|
/
|
/
|
/
|
/
|
192
|
448
|
140
|
140
|
21
|
|
010.20.0414
|
486
|
415.5
|
342
|
412.5
|
460
|
368
|
24
|
24
|
/
|
/
|
/
|
/
|
/
|
248
|
560
|
111
|
169
|
29
|
|
010.20.0544
|
616
|
545.5
|
472
|
542.5
|
590
|
498
|
32
|
32
|
/
|
/
|
/
|
/
|
/
|
325
|
740
|
123
|
188
|
37
|
|
010.20.0644
|
716
|
645.5
|
572
|
642.5
|
690
|
598
|
36
|
36
|
/
|
/
|
/
|
/
|
/
|
385
|
880
|
131
|
200
|
44
|
|
010.20.0744
|
816
|
745.5
|
672
|
742.5
|
790
|
698
|
40
|
40
|
/
|
/
|
/
|
/
|
/
|
445
|
1010
|
138
|
211
|
52
|
|
010.20.0844
|
916
|
845.5
|
772
|
842.5
|
890
|
798
|
40
|
40
|
/
|
/
|
/
|
/
|
/
|
510
|
1150
|
145
|
222
|
60
|
|
010.20.0944
|
1016
|
945.5
|
872
|
942.5
|
990
|
898
|
44
|
44
|
/
|
/
|
/
|
/
|
/
|
570
|
1280
|
151
|
231
|
67
|
|
010.20.1094
|
1166
|
1095.5
|
1022
|
1092.5
|
1140
|
1048
|
48
|
48
|
/
|
/
|
/
|
/
|
/
|
660
|
1490
|
160
|
244
|
77
|
|
